| Total Power | 650 Watts | ||
| 80 PLUS Efficiency | Bronze | ||
| AC Input Rating | 100 - 240V | ||
| Input Current | 10A-5A | ||
| Frequency | 47 - 63Hz | ||
| PSU Form Factor | ATX | ||
| Modular | No | ||
| Dimensions | 150mm (W) x 86mm (H) x 125mm (L) | ||
| Weight | 1.9 | ||
| Fan | Sleeve Bearing | 120mm | |
| MTBF hours | 100,000 hours | ||
| Multi-GPU ready | No | ||
| Zero RPM Mode | No | ||
| iCUE Compatibility | No | ||
| Connector | Type | Connectors (Cable x Connectors Per Cable) |
Total Length |
| ATX Cable 24 Pin (20+4) | 1 x 1 | 550mm (± 10mm) | |
| EPS/ATX12V 8 Pin (4+4) Cable | 2 x 1 | 600mm (± 10mm) | |
| PCIe 8 Pin (6+2) Cable | 1 x 2 | 670mm (± 10mm) | |
| SATA Cable (3 SATA) | 2 x 3 | 690mm (± 10mm) | |
| SATA-PATA-PATA-FDD | 1 x 4 | 810mm (± 10mm) | |
| Protections Technology | OVP (Over Voltage) UVP (Under Voltage) SCP (Short Circuit) OTP (Over Temp) OPP (Over Power) |
||
| Warranty | 3 years | ||
| Package contents | CV Series Power Supply AC power cord Cable ties Mounting screws Warranty Documentation |
||
